Testing and Certification Standards for Robotic Vacuum (Mopping) Cleaners: CCC

1. Product Overview

A robotic vacuum cleaner is a representative product of the smart cleaning appliance category. Equipped with autonomous navigation, path planning and self-recharging capabilities, it replaces manual labour in sweeping, vacuuming and mopping floors. As living standards rise in China and the smart-home ecosystem matures, a product once sold mainly in European and North American markets is now entering Chinese households at an accelerating pace, with market penetration growing year by year.


At the same time, consumers are paying ever closer attention to product safety and reliability. Robotic vacuum cleaners fall within the scope of China Compulsory Product Certification (CCC)​ — classified under the "Household and Similar Electrical Appliances" category, specifically the vacuum cleaner product line. Such products must be tested by a qualified third-party laboratory against the applicable national standards and obtain compulsory certification before they can be placed on the market. Compliance testing is therefore both a statutory market-access requirement and the foundation on which a manufacturer builds its quality reputation.


2. Standards Applied

2.1 Basis for compulsory certification

Robotic vacuum cleaners incorporate self-propelled movement, a docking station and motorized cleaning heads. Clauses in GB/T 4706.7 addressing "battery-powered automatic cleaners" and "docking stations" are therefore key test items; manufacturers should verify these before submitting samples.

2.2 Environmental requirements (restriction of hazardous substances)

2.3 Battery standards (selected by battery type)

2.4 Recommended performance standards

QB/T 4833—2023 Household and Similar Cleaning Robots is the industry reference for evaluating the performance of robotic vacuum cleaners. It covers dust removal efficiency, coverage rate, minimum passable gap and height, threshold-crossing capability, run time on a single charge, operating noise and other metrics — suitable for product benchmarking and for substantiating performance claims.


3. Test Items

(A) Safety items (GB/T 4706 series)

1. Marking and instructions

2. Protection against access to live parts

3. Power input and current

4. Leakage current and electric strength at operating temperature

5. Resistance to moisture, heat and fire

6. Leakage current and electric strength (at ambient temperature)

7. Construction (including checks of anti-fall and boundary-sensing devices)

8. Connection to power supply and external flexible cords

9. Earthing provisions

10. Clearances, creepage distances and solid insulation


(B) Environmental item

1. Restriction of hazardous substances (China RoHS)


(C) Battery items

1. Battery capacity and battery-related safety items

Practical note: in recent supervision spot-checks of robotic vacuum cleaners conducted by market regulators, "marking and instructions" and "construction" have been the most frequent non-conformities — the former usually involving missing nameplate information or incomplete warnings, the latter usually involving the absence of a boundary-sensing (anti-fall) device. A targeted self-check before submission can significantly reduce the cost of rework.


4. Documents Required for Testing

1. Test application form (including basic information such as product type and model number)

2. Packaging declaration

3. A complete set of circuit diagrams: circuit schematic and electrical wiring diagram (A4 size)

4. Product user manual

5. Bill of materials / parts list (list of critical components and safety components)

6. Product general assembly drawing (structural drawing) and structural drawings of major components (A4 size)

7. Draft of the product nameplate (rating label)

8. Other supplementary documents (e.g. certification certificates for critical components, battery specification sheet)


5. Procedure for Obtaining a Quality Inspection Report

1. Submit the application​ — file a testing application with Beice Testing (NT Testing), complete the application form and specify the product type, model and serial number.

2. Confirm the test plan​ — agree on the test items, applicable standards, turnaround time and fees.

3. Send the samples​ — dispatch samples to the Beice Testing laboratory as agreed.

4. Carry out the testing​ — the laboratory performs the tests in accordance with the standards and issues an electronic report for the client's review.

5. Issue the final report​ — once the client confirms the report is correct, the hard-copy report is issued and delivered.


Appendix: Key Revisions in This Version
